Country of Origin: Made in USA.
Cost: $7.22 per roll. 6 Rolls to a case.
Best In Class for Abrasion and Solvent Resistance.
Our Heat Shield Resin provides Best in Class Heat Resistance: Up to 390 degrees Fahrenheit which is 100 degrees higher than Zebra’s 5095. This ribbon rocks if your package goes through a heat tunnel or undergoes heat sterilization.
LabelStock (a.k.a Substrate):
Vinyl (Topcoat), Flood-Coated, Polyesters (Gloss Topcoat), Polyesters (Matte Topcoat), Polymide, Polyethylene, Polyolefin, Polypropylene, Valeron, Nylon, Overlaminates and many others.
These Resin ribbons are coated side in (a.k.a ink on the inside). Inner diameter (core size) of this ribbon is 1” (25.4mm). These ribbons can reach print speeds of up to 8 IPS (inches per second) and have an ink transfer temperature of 199°C (390°F).
We are so Confident in This Ribbon Formula, We will Provide a Free Ribbon Sample. Test Your Label Stock and Printer. Remove all Doubts. Call Us at: 1-800-434-9011
Part Number Compatibility: 18105246, T23147ZA, E-FA040360 & FAR310-040360
- Ribbon width should be 1/4 to 1/2 inch wider than the label or label carrier (backing of label). If you go too wide on the ribbon, you run the risk of causing the ribbon to wrinkle. If you go to narrow you will experience a reduced lifespan of the printhead.
- The duller side of the ribbon is the ink coated side. This ribbon’s ink is on the inner side of the ribbon. The shiny side is on the outside and duller side faces in.
- Our ribbon’s backcoating is formulated for printhead protection. The backcoating creates a protective barrier that results in significantly less build-up on your printhead’s heating element.
- Our ribbon’s ink formulation dissipates static, preventing static build-up and reducing the threat of printing voids or the potential for a spark burning out a printhead.
- Our Heat Shield Resin ribbon is approved by the following Agencies: FDA (indirect food contact), UL, REACH & RoHS
- Our ribbons are ISO 9001 Quality Management and ISO 14001 Environmental Management certified
- Our ribbon’s recommended shelf life is one year. Avoid high humidity and direct sunlight during storage. Storage temperature should be 41°F to 95°F (5°C to 35°C) at 20% to 85% Relative humidity.
Formula Compatibility: R300, V300, Zebra 5095, Zebra 6200, Zebra 4100, Zebra 4800, Zebra 6100, B324, B325, Z302, AXR 1, AXR 7+, HL21, HL49, HL72, LR21, NK22, NK45, SP330, B110C, B120HS, TD331, US310, US450
If You do not See Your Printer Model Call Us. We can Match You with the Correct Ribbon 1-800-434-9011.
Printer Models Certified for This Resin Ribbon:
Datamax: 432, 630, 850, A-4212, A-4310, A-4408, A-4606, A-4608, A-6212, A-6310, Allegro, Allegro 2, Allegro XL, DMX 400, DMX 4000, DMX 430, DMX 600, DMX 800, DMX 8500, E-4203, E-4204B, E-4205A, E-4205e Mark II, E-4206L, E-4206P, E-4304B, E-4304e, E-4305A, E-4305L, E-4305P, E-Class Mark II, E-Class Mark III, Fargo, H-4212, H-4212X, H-4310, H-4310X, H-4408, H-4606, H-4606X, H-6210, H-6212X, H-6308, H-6310X, H-8308X, H-Class, I-4206, I-4207, I-4208, I-4210, I-4212, I-4212e, I-4308, I-4310, I-4406, I-4604, I-4606, I-Class, M-4206, M-4208, M-4210, M-4306, M-Class, M-Class Mark II, Nova4 TT, Nova6 TT, PE-42, PE-43, PE Series, Prodigy, Prodigy Max, Prodigy Plus, W-6208, W-6308, W-8306, W-8308, W-Class
CAB: A2+, A4+, A4.3+, A6+, A8+, Mach 4, XC4, XC6, XD4
Citizen: C.Itoh 400, C.Itoh C4TT-00, C.Itoh M8, C.Itoh S4, C.Itoh S4 Plus, C.Itoh T4, C.Itoh T6, C.Itoh Terminator, C.Itoh X4, C.Itoh Z4, CLP 2001, CLP 4080, CLP 4081, CLP 4121, CLP 6001, CLP 6002, CLP 621, CLP 631, CLP 6401, CLP 7001, CLP 7002, CLP 7102, CLP 7201, CLP 7202, CLP 7401, CLP 7301e, CLP 8301, CLP 9001, CLP 9301, CL S621, CL S6621, CL S700, CL S703
Brady: 2023, 2024, 2461, 3481, 6441, BP-PR 200 PLUS, BP-PR 300 Plus, BP-PR 600 Plus, Calypso 100, Calypso 200, Calypso 300, IP 300, IP 600, MAX 306, MAX 308, PAM 3600 Series
Markem: Smart Date 1
Printronix: 1000, SL4M, T3000, T3204, T3304, T3306, T3308, T3400, T4M
And Many More!
